| Tên thương hiệu: | FIREPOWER |
| Số mẫu: | 16475C |
| MOQ: | 1 |
| giá bán: | 200$ |
| Điều khoản thanh toán: | L/C, D/P, T/T. |
| Khả năng cung cấp: | 1 tuần cho mẫu |
| Parameter | Test Conditions | Max | Typical | Minimal | Unit |
|---|---|---|---|---|---|
| Gyroscope | |||||
| Measuring range | ±500 | °/sec | |||
| Scale factor | X_GYRO_OUT and X_GYRO_LOW (32-bit) | 2,621,440 | LSB/°/sec | ||
| Scale factor nonlinearity | Best straight line fit, input angular rate 500dps | 100 | ppm | ||
| Zero-bias instability | Allan, 1 σ | 2.5 | 3.0 | °/h | |
| Random walk | 1 σ | 0.15 | 0.20 | °/√h | |
| Bandwidth | -3dB | 345 | Hz | ||
| Accelerometer | |||||
| Measuring range | ±8 | g | |||
| Scale factor | X_ACCL_OUT and X_ACCL_LOW (32-bit) | 2,621,44000 | LSB /g | ||
| Zero-bias instability | Allan, 1 σ | 25 | 50 | ug | |
| Bandwidth | -3dB | 393 | Hz | ||
| General Specifications | |||||
| Start time | 1000 | ms | |||
| Update speed | 2.0 | kSPS | |||
| Operating voltage range | VDD | 3.0 | 3.6 | V | |
| Supply current | VDD = 3.3 V | 17 | 20 | mA | |
