| Tên thương hiệu: | FIREPOWER |
| Số mẫu: | 16488ha |
| MOQ: | 1 |
| giá bán: | 200$ |
| Điều khoản thanh toán: | D/A, L/C, T/T. |
| Khả năng cung cấp: | 500pcs |
| Attribute | Value |
|---|---|
| Gyro Dynamic measuring range | ±450°/s |
| Zero-bias stability (@ Allan variance) | ≤0.3 °/h |
| Acceleration range | ±20g |
| Communication Interface | 1-way SPI |
| Operating voltage | 3.3V |
| Parameter | Test conditions | Typical value | Maximum value | Unit |
|---|---|---|---|---|
| Dynamic measuring range | ±450 | º/s | ||
| Zero-bias instability | Allan variance, better than | 0.3 | º/h | |
| Random walk | 1σ | 0.15 | º/√h | |
| Bandwidth (-3dB) | 250 | Hz |
| Parameter | Test conditions | Typical value | Maximum value | Unit |
|---|---|---|---|---|
| Dynamic measuring range | ±20 | g | ||
| Zero bias stability | Allan variance | 0.07 | mg | |
| Random walk | 1σ | 0.029 | m/s/√h | |
| Bandwidth (-3dB) | 250 | Hz |
| Parameter | Test conditions | Typical value | Maximum value | Unit |
|---|---|---|---|---|
| Voltage | Direct current | 3.3 | V | |
| Power consumption | 1.5 | 1.5 | W |
| Parameter | Test conditions | Minimum value | Maximum value | Unit |
|---|---|---|---|---|
| Operating temperature | -45 | 85 | ℃ | |
| Storage temperature | -55 | 85 | ℃ |
